Leg & Stand Supports
A2001 Heavy Duty Channel Support
- Maximum Capacity: 4,000 Pounds
- Head: 10 Gauge Formed Steel
- Upright: 10 Gauge Formed Steel
- Foot Plate: 7 Gauge Formed Steel
- Hardware: 1/2″ Nuts and Bolts
- Top of Support Vertical Adjustment Range: 13″-16″, 15″-21″, 27″-35″, 34″-46″, 45″-57″, 56″-80″, 79″-103″, 102″-143″
- Available Widths: 12″ to 63″
- Finish: Standard finish for painted components is Metzgar Medium Blue or Vista Green
Notes:
- Start with the required carrying surface elevation of the conveyor.
- Deduct the amount in the table below.
- This is the top of support elevation.
- Order the support that includes elevation.
Order Separately:
- Diagonal Bracing
- Hardware to anchor supports to the floor is not included.
- All adjustment ranges are from the floor to top of support.
| Conveyor Series | Distance Top of Conveyor to Bottom of Frame |
|---|---|
| Wheel Gravity | 2 29/32" |
| SD138 Gravity | 2 3/4" |
| MD190 Gravity | 3 13/16" |
| HD250 Gravity | 4 5/16" |
| 438 Lineshaft | 4 9/16" |
| 440 Lineshaft | 4 13/16" |
| 445 Lineshaft | 9 5/16" |
| 701 Belt | 6 1/8" |
| 801 Belt | 6 1/8" |
| 401 Belt Driven | 8 15/16" |
| 430 Belt Driven | 8 15/16" |
| 435 Belt Driven | 6 13/16" |
| 460 Belt Driven | 8 1/8" |
| 470 Chain Driven | 4 9/16" |
| 480 Chain Driven | 4 5/16" |
| 490 Chain Driven | 6 3/8" |
